M24LR64E-R
M24LR64E-R memory initial state
Doc ID 022712 Rev 3
41/140
6
M24LR64E-R memory initial state
The device is delivered with all bits in the user memory array set to 1 (each byte contains
FFh).
The DSFID is programmed to FFh and the AFI is programmed to 00h.
Configuration byte set to F4h:
●
Bit 7 to bit 4: all set to 1
●
Bit 3: set to 0 (RF BUSY mode on RF WIP/BUSY pin)
●
Bit 2: set to 1 (Energy harvesting not activated by default)
●
Bit 1 and bit 0: set to 0
