1 / 20 page

Feature and Applications

UL E223037



ROHS Compliant & Halogen Free



Excellent for high density applications



Surface Mount, 0805, 1206, 1210, 1812, 2920



Faster time to trip than standard SMD devices



Lower resistance than standard SMD devices



Operation Current: 0.05A ~ 3.0A



Maximum Voltage: 6V ~ 60V



Temperature Range: -40ºC to 85ºC

MPTS

0805

L

10

R

Meritek Series

Size

0805

1206

1210

1812

2920

Current rating

Semi-circular Termination

Polymeric PTC

MPTS Series

Rev.7
