C-47

www.ittcannon.com

Straight PCB Hole Pattern

PCB Hole Pattern

D*MA High Density

24,99 (.984)

2,29 (.090)

2,04 (.080)

1,40 (.055)

0,89 (.035)

0,25 (.010)

33,32 (1.312)

2,29 (.090)

1,78 (.070)

0,51 (.020)

0,64 (.025)

1,65 (.065)

47,04 (1.852)

2,29 (.090)

1,78 (.070)

0,51 (.020)

0,64 (.025)

1,64 (.065)

63,50 (2.500)

1,63 (.064)

0,79 (.031)

0,42 (.0165)

2,41 (.095)

1,99 (0785)

61,11 (2.406)

2,41 (.095)

1,21 (.048)

63,50 (2.500)

1,83 (.072)

0,58 (.023)

0,62 (.024)

2,41 (.095

1,79 (070)

(Mating Side)

SIZE E

15 Contacts

SIZE A

26 Contacts

SIZE B

44 Contacts

SIZE C

62 Contacts

SIZE D

78 Contacts

SIZE F

104 Contacts

Face view, pin insert for plug

(use a mirror image for receptacle)

Dimension X

1,98 (.078) for sizes E, A, B, C

2,08 (.082) for size D

Recommended PC hole for signal contacts

0,90 (.035) min for terminations ? 0,51 (.020)

1,00 (.040) min for terminations ? 0,57 (.022)

Dimensions shown in inches (mm)

Specifications and dimensions subject to change
