ADRF6750
Rev. A | Page 26 of
40
VCO Autocalibration
The VCO uses an autocalibration technique to select the correct
VCO and band, as explained in the Voltage-Controlled Oscillator
(VCO) section. Register CR24, Bit 0, controls whether the auto-
calibration is enabled. For normal operation, autocalibration needs
to be enabled. However, if using cumulative frequency steps of
100 kHz or less, autocalibration can be disabled by setting this
bit to 1 and then a new acquisition is initiated by writing to
Register CR0.
Attenuator
The attenuator can be programmed from 0 dB to 47 dB in steps
of 1 dB. Control is through Register CR30, Bits[5:0].
Revision Readback
The revision of the silicon die can be read back via Register CR33.
