VF8143

Preliminary

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

4 of 5

www.unisonic.com.tw

QW-R502-956.a



TYPICAL APPLICATION CIRCUIT

UTC VF8143

75Ω Video Cables

220µF

Video

SoC

ROUT

IN1

OUT1

75Ω

220µF

GOUT

IN2

OUT2

75Ω

220µF

BOUT

IN3

OUT3

75Ω

VCC

GND

DVD Player or STB

+ 1.0

µF

+5V

0.1

µF

75Ω
