 2 / 3 page
background image
DIM
Min
Max
DIM
Min
Max
A
28.0
30.0
E
17.60
18.60
B
11.50
F
13.80
14.80
C
10.80
12.20
G
16.10
17.10
D
28.0
30.0
H
16.10
17.10
KBPC_Pkg_Drawing Rev281005
KBPC Square Leaded Plastic Package
All Dimensions are in mm
Continental Device India Limited
Data Sheet
Page 2 of 3
Continental Device India Limited
An ISO/TS 16949, ISO 9001 and ISO 14001 Certified Company
