Specifications

OUTPUT

Output Volt Amp Capacity (VA)

2200

Output kVA capacity (kVA)

2.2

Output Watt Capacity (watts)

1700

Output kW capacity

1.7

Output power factor

0.8

Nominal Output Voltage(s)

Supported

120V

Frequency compatibility

60 Hz

Output voltage regulation (line mode)

-13% / +5%

Output voltage regulation (Battery

mode)

+/- 5%

Built-in UPS output receptacles

6 5-15R outlet(s)

Built-in controllable switched load

banks

Two switchable single outlet 5-15R load banks

Output AC waveform (AC mode)

Sine wave

Output AC waveform (battery mode)

PWM sine wave

INPUT

Rated input current (at maximum

load)

15A

Nominal Input Voltage(s) Supported

120V AC

UPS input connection type

5-15P

Input circuit breaker

20A

UPS Input cord length (ft.)

UPS Input cord length (m)

2.4

Recommended Electrical Service

20A 120V

Input cord length (ft.)

Input cord length (m)

2.4

Phase

Single-Phase

BATTERY

Full load runtime (minutes)

11 min. (1700w)

Half load runtime (minutes)

27 min. (850w)

Expandable battery runtime

Extended runtime supported via optional external battery packs

2 / 5
