32 / 38 page

Package mechanical data

M24C08-W M24C08-R M24C08-F

32/38

DocID023924 Rev 4

Figure 16. PDIP8 – 8-pin plastic DIP, 0.25 mm lead frame, package outline

1. Drawing is not to scale.

2. Not recommended for new designs.

Table 20. PDIP8 – 8-pin plastic DIP, 0.25 mm lead frame, package mechanical data

Symbol

millimeters

inches(1)

1. Values in inches are converted from mm and rounded to four decimal digits.

Typ.

Min.

Max.

Typ.

Min.

Max.

–

5.33

–

0.2098

–

0.38

–

0.0150

–

3.30

2.92

4.95

0.1299

0.1150

0.1949

0.46

0.36

0.56

0.0181

0.0142

0.0220

1.52

1.14

1.78

0.0598

0.0449

0.0701

0.25

0.20

0.36

0.0098

0.0079

0.0142

9.27

9.02

10.16

0.3650

0.3551

0.4000

7.87

7.62

8.26

0.3098

0.3000

0.3252

6.35

6.10

7.11

0.2500

0.2402

0.2799

2.54

–

0.1000

–

7.62

–

0.3000

–

10.92

–

0.4299

3.30

2.92

3.81

0.1299

0.1150

0.1500
