ASB Inc.

 sales@asb.co.kr  Tel: +82-42-528-7223

November 2012

ASL13W

5-3000 MHz MMIC Amplifier

1) OIP3 is measured with two tones at an output power of +10 dBm/tone separated by 1 MHz.

Parameters

Units

Min

Typ

Max

Testing Frequency

MHz

2000

Gain

dB

12

13

S11

dB

-20

S22

dB

-15

Output IP3

dBm

36

38

Noise Figure

dB

0.9

1.1

Output P1dB

dBm

20

22

Current

mA

45

60

80

Device Voltage

V

5

* Please find the max. input power data from http://www.asb.co.kr/pdf/Maximum_Input_Power_Analysis.pdf

Parameters

Units

Typical

Frequency

MHz

150

900

2000

2450

2600

Gain

dB

23.5

19

13

11.5

11

S11

dB

-15

-20

-20

-20

-18

S22

dB

-11

-15

-15

-16

-15

dBm

33

35.5

38

37.5

37.5

Noise Figure

dB

0.6

0.9

0.9

1.1

1.15

Output P1dB

dBm

21.5

22

22

22

22

Current

mA

60

60

60

60

60

Device Voltage

V

5

5

5

5

5

Parameters

Rating

Operating Case Temperature

-40 to

85C

Storage Temperature

-40 to

150C

Device Voltage

+6 V

Operating Junction Temperature

+150

C

Input RF Power (CW, 50ohm matched)*

22 dBm

Features

Description

Package Style: SOT-363

Typical Performance

Absolute Maximum Ratings

·13 dB Gain at 2000 MHz

·22 dBm P1dB at 2000 MHz

·38 dBm OIP3 at 2000 MHz

·0.9 dB NF at 2000 MHz

·MTTF > 100 Years

·Single Supply

The ASL13W, a wideband linear low noise amplifier

MMIC, has a low noise and high linearity at low bias

current, being suitable for use in both receiver and

transmitter of telecommunication systems up to 3

GHz. S11 down to

–20 dB is easily achieved for low

noise application to provide a good productivity. The

amplifier is available in an SOT-363 package and

passes through the stringent DC, RF, and reliability

tests.

Application Circuit

· IF ( 50 ~ 450 MHz )

· TETRA

· LTE

· CDMA

· GSM

· WCDMA

· 350 ~ 500 MHz

· 960 ~ 1200 MHz

· 2300 ~ 2600 MHz

Product Specifications

Pin Configuration

Pin No.

Function

1

RF IN

4

RF OUT / Bias

2,3,5,6

GND
