UPS Housing Material

PVC

ENVIRONMENTAL

Operating Temperature Range

+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature Range

+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity

0 to 95%, non-condensing

AC Mode BTU / Hr. (Full Load)

82.4

AC Mode Efficiency Rating (100%

Load)

99%

COMMUNICATIONS

Communications Interface

DB9 Serial; Contact closure

Network Monitoring Port Description

Supports detailed monitoring of UPS and site power conditions; contact closure communications via two additional

DB9 ports (3 total)

PowerAlert Software

Included

Communications Cable

3 DB9 cables included

LINE / BATTERY TRANSFER

Transfer Time

4 ms. typical

Low Voltage Transfer to Battery

Power (Setpoint)

87

High Voltage Transfer to Battery

Power (Setpoint)

140

SPECIAL FEATURES

Cold Start (Startup in Battery Mode

During a Power Failure)

Cold-start operation supported

Green Energy-Saving Features

Individually controllable load banks

CERTIFICATIONS

UPS Certifications

Meets FCC Part 15 Category A (EMI); ROHS (Restriction of Hazardous Substances); Tested to CSA (Canada);

Tested to NOM (Mexico); Tested to UL1778 (USA)

WARRANTY

Product Warranty Period (Worldwide)

2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty.

Connected Equipment Insurance

(U.S., Canada & Puerto Rico)

$250,000 Ultimate Lifetime Insurance

© 2015 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous improvement.

Specifications are subject to change without notice. Photos may differ slightly from final products.

4 / 4
