JH395320480CCNFNNTZCWC Datenblatt(PDF) 10 Page - Jewel Hill Electronic |
|
|
|||||||||||||||||||||||||||||
JH395320480CCNFNNTZCWC Datenblatt(HTML) 10 Page - Jewel Hill Electronic |
|
|
10 / 23 page  JH395320480C VER: 1.0 - 9 - Issue date: 2013/08/15 JEWEL HILL ELECTRONIC CO.,LTD. 7.Pin Description Pin NO. Symbol Description 1 LED_K6 LEDK1- 2 LED_K5 LED- 3 LED_K4 LED- 4 LED_K3 LED- 5 LED_K2 LED- 6 LED_K1 LED- 7 LED_A LED+ 8 GND Ground 9 LED_K7 LED- 10 LED_K8 LED- 11 IM0 The MPU system interface mode select pin 0 12 IM1 The MPU system interface mode select pin 1 13 IM2 The MPU system interface mode select pin 2 14 RESET System Reset Pin 15 NC NC 16-18 NC NC 19-36 D17-D0 Data Bus 37 NC NC 38 NC NC 39 RD Read execution control pin 40 WR Write execution control pin 41 RS Data/Command Write Select pin 42 CS Chip select input pin 43 FMARK Output a frame head pulse signal 44 IOVCC Power Supply(1.8-2.8V) 45 VCC Power Supply(2.8V) 46 GND Ground 47 XR Touch panel Right side(NC) 48 YD Touch panel down side(NC) 49 XL Touch panel Left side(NC) 50 YU Touch panel Up side(NC) |
|
|
