DMC3025LSD

Document number: DS35717 Rev. 7 - 2

9 of 10

www.diodes.com

February 2015

© Diodes Incorporated

DMC3025LSD

0.001

0.01

0.1

1

0.00001

0.0001

0.001

0.01

0.1

1

10

100

1000

t1, PULSE DURATION TIMES (sec)

Figure 25 Transient Thermal Resistance

D = Single Pulse

D = 0.005

D = 0.01

D = 0.02

D = 0.05

D = 0.1

D = 0.3

D = 0.5

D = 0.7

D = 0.9

R

(t) = r(t) * R

thja

thja

R

= 83C/W

thja

Duty Cycle, D = t1/ t2

Package Outline Dimensions

Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for the latest version.

Suggested Pad Layout

Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.

SO-8

SO-8

Dim

Min

Max

A

-

1.75

A1

0.10

0.20

A2

1.30

1.50

A3

0.15

0.25

b

0.3

0.5

D

4.85

4.95

E

5.90

6.10

E1

3.85

3.95

e

1.27 Typ

h

-

0.35

L

0.62

0.82

θ

θ

θ

θ

0°

8°

All Dimensions in mm

Dimensions

Value (in mm)

X

0.60

Y

1.55

C1

5.4

C2

1.27

Gauge Plane

Seating Plane

Detail ‘A’

Detail ‘A’

E

E1

h

L

D

e

b

A2

A1

A

A3

X

C1

C2

Y
