AXLE2000 Rev.1

www.axtal.com

Roemerring 9

Drawing D1

fon: +49 (6261) 939834

D-74821 Mosbach

Page 1(4)

fax: +49 (6261) 939836

Germany

E-mail: info@axtal.com

GmbH & Co. KG

Specification

AXLE2000

Rev.: 1

Date: 2016-02-01

Oscillator type:

SHF Low Phase Noise TCXO in Connectorized Package

Parameter

min.

typ.

max.

Unit

Condition

Frequency range

3

12

GHz

Multiplication (Note 2)

Frequency stability

Initial tolerance @ +25°C

±1.0

ppm

vs. operating temperature range

±0.5 to ±5

See tables 1 & 2

ppm

Option 1 & 2

vs. supply voltage variation (pushing)

±0.1

ppm

vs. load change (pulling)

±0.1

ppm

Long term (aging) 1

±1.0

ppm

after 30 days operation

RF output

Signal waveform

Sine wave

50

Ω

±5%

Output level

+10

+13

dBm

Harmonics

-30

dBc

Sub-harmonics

-40

dBc

Spurious

-80

dBc

(Note 3)

PLL Products

-60

dBc

Phase noise

-120

-110

dBc/Hz @ 100 kHz

Lock detect (LD) output

2.3

0

3.3

1.0

V

V

Out of lock

Locked

11.4

12.0

12.6

V

Current consumption

250

350

mA

Enclosure (see drawing) (LxWxH)

50.0x50.0x21.0 max.

mm

Weight

60

g

Packing

Palette

Notes:

1.

Terminology and test conditions are according to IEC60679-1 and MIL-PRF-55310, unless otherwise stated

2.

3.

Internal PLL with TCXO reference

Absolute Maximum Ratings

Parameter

min.

max.

Unit

Condition

-0.5

V

Storage Temperature

-55

+105

°C
