PL602-35/-37/-38/-39

750kHz

– 800MHz Low Phase Noise Multiplier XO

Universal Low Phase Noise IC’s

PIN DESCRIPTIONS PL602-37/-39 (see previous page for PL602-35/-38)

Name

TSSOP

Pin number

3x3mm QFN

Pin number

Type

Description

XIN

2

12

I

Crystal input. See Crystal Specification on page 4.

XOUT

3

13

I

Crystal output. See Crystal Specification on page 4.

OE

6

16

I

Output enable pin (see OE logic state table on page 1).

GND

7,8,9,10,14

1,2,3,4,8

P

Ground.

CLKT

11

5

O

LVDS True output for PL602-39.

No Connect for PL602-37

CLKC

13

7

O

LVDS Complementary output for PL602-39

LVCMOS out for PL602-37

SEL0

16

10

I

Multiplier selector pins. These pins have an internal pull-up

that will default SELx to ‘1’ when not connected to GND.

SEL1

15

9

I

SEL2

5

15

I

SEL3

4

14

I

VDD

1, 12

6,11

P

+3.3V power supply.
