(a)

(c)

(b)

(e)

(d)

1. PART NO. EXPRESSION :

(b) Dimension code

(c) Type code : LP ( Low Profile )

(a) Series code

2. CONFIGURATION & DIMENSIONS :

A

4. MATERIALS :

SUPERWORLD ELECTRONICS (S) PTE LTD

3. SCHEMATIC :

(d) Inductance code : 1N8 = 1.8nH

(e) Tolerance code : G = ± 2%, J = ± 5%, K = ± 10%

SCI0805LP SERIES

WIREWOUND CHIP INDUCTORS

PG. 1

NOTE : Specifications subject to change without notice. Please check our website for latest information.

06.02.2015

PCB Pattern

2.29 Max.

1.03 Max.

0.51 Ref.

1.73 Max.

0.44 Ref.

1.02 Ref.

1.78 Ref.

1.02 Ref.

1.27 Ref.

B

CDE

F

G

H

S C I 0 8 0 5 L P - 1 N 8 K F

I

J

I

E

D

C

B

Unit:m/m

0.76 Ref.

J

I

(f) F : RoHS Compliant

(f)

(a) Ceramic Core

(c) Electrode (Ag/Pd+Ni+Sn)

(b) Magnet Wire

b

d

a

c

(d) UV Glue
