Functional description
49
4.7
Overtemperature protection
It is recommended that the device never exceeds the maximum allowable junction
temperature. This temperature increase is mainly caused by the total power dissipated by
the integrated power MOSFET.
To avoid any damage to the device when reaching high temperature, the LED6000
implements a thermal shutdown feature: when the junction temperature reaches 170 °C
(typ.) the device turns off the power MOSFET and shuts-down.
When the junction temperature drops to 155 °C (typ.), the device restarts with a new soft-
start sequence.
