background image
STLED325
Display RAM address and display mode
Doc ID 17576 Rev 1
41/62
5
Display RAM address and display mode
The display RAM stores the data transmitted from an external device to the STLED325
through the serial interface. The addresses are as follows, in 8-bits unit:
“0” in memory means GND on outpu; ‘1” in memory means VCC on output.
Table 25.
Bit map for segment 1 to segment 8
Seg1
Seg4
Seg8
10 HL
10 HU
Dig1
11 HL
11 HU
Dig2
12 HL
12 HU
Dig3
13 HL
13 HU
Dig4
14 HL
14 HU
Dig5
b0
b3
b4
b7
XX HL
XX HU
