ELECTRICAL CHARACTERISTICS (TA = 0°C to 70°C unless otherwise specified)
INPUT
OUTPUT
* Typical values at TA = 25°C
ICPL0452 / ICPL0453 / ICPL0500 / ICPL0501
ISOCOM
COMPONENTS
Parameter
Symbol
Test Condition
Min
Typ.*
Max
Unit
Forward Voltage
VF
IF = 16mA
1.5
1.8
V
Reverse Voltage
VR
IR = 10µA
5.0
V
Temperature
Coefficient of VF
ΔVF/ΔTA
IF = 16mA
-1.6
mV/°C
Parameter
Symbol
Test Condition
Min
Typ.*
Max
Unit
Logic High Output
Current
IOH
IF = 0mA, VO = VCC = 5.5V,
TA = 25°C
0.001
0.5
μA
IF = 0mA, VO = VCC = 15V,
TA = 25°C
0.01
1
IF = 0mA, VO = VCC = 15V
50
Logic Low Supply
Current
ICCL
IF = 16mA, VO = Open,
VCC = 15V
140
200
μA
Logic High Supply
Current
ICCH
IF = 0mA, VO = Open,
VCC = 15V, TA = 25°C
0.01
1
IF = 0mA, VO = Open,
VCC = 15V
2
μA
