2

Material Specifications

Description

Material

Plating

Contact

Brass

Gold

30 µin minimum

Insulation

PTFE

Body

Brass

Nickel

100 µin minimum

.

Environmental Specifications

Temperature

Operating Range

-40 to +60 deg C

Plotted and Other Data

Notes:

MCX Plug Right Angle Connector Crimp/Solder Attachment for RG174, RG316, RG188, LMR-100, PE-B100, PE-C100, 0.100

inch from Pasternack Enterprises has same day shipment for domestic and International orders. Our RF, microwave and

millimeter wave products maintain a 99% availability and are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: MCX Plug Right Angle Connector Crimp/Solder Attachment for RG174, RG316, RG188, LMR-

100, PE-B100, PE-C100, 0.100 inch PE4553

URL: https://www.pasternack.com/mcx-plug-standard-rg174-rg316-rg188-connector-pe4553-p.aspx

PE4553 REV 1.2

RF Connectors Technical Data Sheet

PE4553

MCX Plug Right Angle Connector Crimp/Solder

Attachment for RG174, RG316, RG188, LMR-

100, PE-B100, PE-C100, 0.100 inch
