LUMINIS.COM

Luminaires may be altered for design improvement or discontinued without prior notice.

Toll free: 866.586.4647 Fax: 514.683.8872

260 Labrosse, Pointe-Claire (QC) Canada H9R 5L5

LUMINIS

TYPE:

QUANTITY:

PROJECT:

CATALOG

NUMBER:

FIXTURE

WATTAGE

VOLTAGE

FINISH

OPTION

OPTION

OPTION

OPTION

1

MATERIALS

Argon is made of corrosion resistant 356 aluminum alloy with a copper (CU)

content of less than 0.1%.

COB LED is assembled on a thick pad housing chamber designed with a

heat sink pattern to optimize heat dissipation and luminaire efficacy. The

power supply is enclosed in an isolated chamber allowing quick access for

electrical maintenance without disturbing the optical chamber.

COB LED is removable and replaceable for ease of maintenance or lighting

upgrade.

ELECTRICAL

LED

POWER SUPPLY

Standard driver is 0-10V dimming-ready (dims to 10%) with:

120-277 multi-volt compatibility (50-60Hz), operating

temperature range of -30ºC/-22ºF to 60ºC/140ºF, output

over voltage protection, output over current protection and

output short circuit protection with auto-recovery.

LED

Type II, III, IV or V light distribution via high performance

optical lenses. Standard 4000K/80CRI. Optional 3000K,

3500K and 5000K

Optional Amber LED for turtle sensitive areas

Wavelengths: 584.5nm to 597nm

LIFE

125,000hrs (L

FINISH

Five-stage preparation process including preheating of cast aluminum parts for air

extraction, and an environmentally friendly alloy sealant. Polyester powder coating

is applied through an electrostatic process and oven cured for long term finish.

MOUNTING

Maximum weight

AR25P/AR25W/AR35P/AR35W: 30lbs (13.6kg)

Maximum weight

AR35FP/AR35FW: 28lbs (12.7kg)

The luminaire is designed for wall or pole. Mounts on a 4” (102) or 5” (127) pole.

CERTIFICATION

Tested to UL1598 and CSA22.2 #250. ETL listed wet location.

Photometric testing performed by an independent laboratory in accordance

with IES LM-79-08 standards at 25ºC. Lumen depreciation in accordance with

IESNA LM80 standards.

Rated IP65.

LED optical chamber is

easily accessible with a

cast aluminum hinged

lens frame.

1

4

3

2

5

6

1- Heavy gauge steel galvanized

mounting plate.

2- Cast aluminum driver housing.

3- Cast aluminum conical top.

4- AR25: White frosted luminous insert

with 10W LED light engine.

AR35: Solid opaque aluminum insert.

AR35F: Flat top sealed cover

5- Cast aluminum conical body.

6- LED optical control silicone lens.

POLE MOUNT

AR25P

EPA: 0.96

WALL MOUNT

AR35P

EPA: 0.96

Luminaire with luminous insert

Fully enclosed Full cut off luminaire

AR25W

AR35W

18” (457)

25” (635)

6.18”

(170)

11.18”

(284)

Luminaire with flat top cover

AR35FW

AR35FP

EPA: 0.80

3”

(76)

6.31”

(160)

AR35FP

ARGON - LED
