background image
TECHNICAL DATA SHEET
ATE-R11-3W
<TOPLITE COB MODULE>
2 / 9
A/1
ATE-R11-3W
SERIES
Revision issued in 2014.
3. PERFORMANCE PARAMETERS
3-1. ABSOLUTE MAXIMUM RATINGS
ITEM
SYMBOL
RATING
UNIT
Power Dissipation
P
4.75
W
Forward Current
IF
120
mA
Reverse Voltage
VR
60
V
Operating Temperature
Topr
- 30 ～ + 85
℃
Storage Temperature
Tstg
- 40 ～ + 100
℃
Junction Temperature
Tjmax
110
℃
Note：
*1. Forward Current allows maximum surge current ≤ 10ms.
*2. Power dissipation and forward current are the values when the LED is used within the range of the derating curve in this data sheet.
