TECHNICAL DATA SHEET

ATE-R23-38W

5 / 9

A/1

ATE-R23-38W SERIES

Revision issued in 2014.

4. RELIABILITY

The reliability of products shall be satisfied with items listed below.

4-1. TEST ITEMS AND TEST CONDITIONS

NO.

TEST ITEM

TEST CONDITIONS

RESULT

Continuous operation test

Ta = 25℃, IF = 840mA × 1000 hours(with Al fin)

PASS

Ta = 80℃, T j≒120℃, IF =840mA × 1000

hours(with Al fin)

Low temperature storage

Ta =-40℃×1000 hours

PASS

High temperature storage

Ta =100℃×1000 hours

PASS

Moisture resistance

Ta =60℃, 90%RH for 1000 hours

PASS

Thermal shock

Ta =-40℃×30minutes～100℃×30minutes, 100

cycle

PASS

4-2. FAILURE CRITERIA

NO.

PARAMETER

SYMBOL

FAILURE CRITERIA

Forward Voltage

VF ＞ Initial value × 1.1

Luminous Flux

Ф ＜ Initial value × 0.7
