TECHNICAL DATA SHEET

ATE-R23-38W

<FOR TOPLITE COB MODULE>

8 / 10

A/1

ATE-R23-38W SERIES

Revision issued in 2014.

5-2. 5000K CHROMATICITY COORDINATES

(Tolerance: x,y ± 0.005)

Range

Chromaticity coordinates

NO.1

NO.2

NO.3

NO.4

CENTER

x

0.3551

0.3376

0.3366

0.3515

0.3447

y

0.376

0.3616

0.3369

0.3487

0.3553

* The percentage of each rank in the shipment shall be determined by TOPLITE.

Chromaticity Diagram

Note: The tolerance of measurement at our tester is VF±3% , Dv±10% , Chromaticity(x,y)±0.005.
