background image
isc website：www.iscsemi.com
isc & iscsemi is registered trademark
2
isc N-Channel MOSFET Transistor
ISCNH360W
ELECTRICAL CHARACTERISTICS
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP
MAX
UNIT
V(BR)DSS
Drain-Source Breakdown Voltage
VGS= 0; ID= 0.25mA
650
--
--
V
VGS(th)
Gate Threshold Voltage
VDS= VGS; ID= 0.25mA
3.0
--
5.0
V
RDS(on)
Drain-Source On-Resistance
VGS= 10V; ID=36A
--
--
0.044
Ω
RG
Gate Resistance
f = 1.0MHz open drain
--
0.3
--
Ω
IGSS
Gate-Body Leakage Current
VGS= ±20V;VDS= 0
--
--
±
100
nA
IDSS
Zero Gate Voltage Drain Current
VDS= 600V; VGS= 0
--
--
10
uA
Dynamic Characteristics
Ciss
Input Capacitance
VGS = 0V,
VDS = 100V,
f = 1.0MHz
--
7837
--
pF
Coss
Output Capacitance
--
221
--
Crss
Reverse Transfer Capacitance
--
13.2
--
Qg
Total Gate Charge
VDD = 520V, ID = 50A,
VGS = 10V
--
165
--
nC
Qgs
Gate-Source Charge
--
50
--
Qgd
Gate-Drain Charge
--
70
--
td(on)
Turn-on Delay Time
VDD = 400V, ID = 50A,
RG = 25Ω
--
103
--
ns
tr
Turn-on Rise Time
--
83
--
td(off)
Turn-off Delay Time
--
543
--
tf
Turn-off Fall Time
--
93
--
