Model TMR2MS24INCC

page 2

SYSTEM SPECIFICATIONS*

MASTERBELT SPECIFICATIONS*

IntercomAudio Channels

2

Simultaneous Listen Paths

True Dual Listen

Headset Connector

4-pin male XLR

MicrophoneType

Dynamic or Electret, auto selected

LCD Display

102 × 80 pixels

Antenna

Internal +2 dBi patch

USB BeltStation Power Supply

Input 100–240V, 0.3A, 50–60 Hz; Output 5V, 1.25A

Battery Life, Rechargeable

Up to 8 hours

Charge Time, Lithium-Polymer Battery

Under 3 hours

Optional Power

3 Standard AA alkaline cells

Battery Life, Alkaline Batteries

Approximately 4 hours

Dimensions (inches)

H 6.1 in. × W 4.0 in. × D 1.75 in.

(156 mm × 102 mm × 44.5 mm)

Weight (with Lithium-Polymer Battery)

14.3 oz (405 g)

Operating Environment

-20°C to 50°C (-4°F to 122°F) | 10% to 90% humidity

RF Frequency

2400 to 2480 MHz

RF Scheme

FHSS with TDMA

Effective Radiated Power

100mW using 2dBi antenna

Receiver Sensitivity

-93 dBm for 10-5 BER

Radio Certification

FCC Part 15.247, ETS 300 328 v1.8.1 rules (apply to

model numbers ending in “EU” only**), Canadian

RSS-210, license free.

Transmission Range

1,000 ft. (304.8 m) under ideal conditions.

500 ft. to 900 ft. (152.4 m to 274.3 m) typical

Audio Dynamic Range

>94dB

Audio Frequency Response

300Hz–3.8KHz with proprietary audio voice shaping

System Latency

Less than 50ms direct

RoHS Compliant

Yes

*Notice About Specifications

While Pliant makes every attempt to maintain the accuracy of the

information contained in this datasheet, this information is subject to

change without notice. Please check our website for the latest system

specifications and certifications.

**TMR2MS24INEU models meet the same specifications and comply

with ETSI standards (300.328 v1.8.1). Non-EU models are non-compliant

with ETSI standards.
