ABOUT

The Tempest2400 2-channel wireless BeltStation operates in conjunction with the Tempest2400 BaseStations. Each Talk button has

individual LED indicators. The Talk button can be latching or momentary. The Call button sends a 2-wire compatible call signal to

any wireless BeltStation and any hardwired intercom device on the intercom channel. BeltStations are provided with a rechargeable

Lithium-Polymer battery capable of nine hours of operation or can be powered by three Standard AA Alkaline batteries. Each

BeltStation has its own back-lit display and menu functions, which allow settings to be changed locally at the BeltStation. When

ordering, reference Part Number TMP-R224 (or TMP-R224-EU for European sales).

TECHNOLOGY

Each BeltStation user may simultaneously Talk/Listen on A and B or toggle between A and B in “Single Listen” mode. Volume is set by rotating the

CH A or CH B rotary control. There are two Talk buttons on each BeltStation, one for each channel. The Talk button enables the microphone signal

for the assigned intercom.

AUDIO

Each full-duplex BeltStation establishes a unique audio path (point-to-point) with the associated 2- or 4-channel BaseStation delivering an

individualized mix minus signal to other BeltStations in the system. Therefore, each BeltStation can monitor a unique mix of intercom channels and

other audio sources.

DURABILITY

The 2-channel BeltStations are made of a weather-resistant ABS co-polymer blend with a high performance polyurethane over-mold.

SEAMLESS ROAMING

Tempest2400 Seamless Roaming is the ability for Tempest2400 BeltStations to move freely from one BaseStation to another without any

intervention from the end user. This allows the implementation of a Tempest wireless intercom system that can cover large areas with multiple

zones or areas in a facility that would not be adequately supported by a single antenna installation. A BeltStation can roam between as many as 16

different BaseStations (coverage areas or zones).

• 2-channel, full-duplex BeltStation

• 2.4GHz, license free operation

• Dual Talk/Listen operation

• Backlit LCD screen shows battery life,

RF signal strength, and more

• Stage Announce Output with relay closure

• 5 individually assignable relay closures at BaseStation

• Lithium-Polymer Rechargeable battery

(or 3 Alkaline AA batteries)

• Weather-resistant enclosure

FEATURES & BENEFITS

• Roaming Features:

» Seamless Roaming of BeltStation

between BaseStations

» Supports Normal, Shared, and Split modes

» Scalable architecture allows for seamless

linked roaming zones

» Seamless handoffs between roaming

zones are automatic

• RoHS compliant

Model TMR22524INCC

Tempest2400 2-Channel BeltStation Technical Data Sheet
