L–16

Dimensions are shown: Inch (mm)

Specifications and dimensions subject to change

www.ck-components.com

L

YM Series

4 Tumbler Miniature Switchlocks

SWITCH AND LOCK FUNCTION

KEYING

LOCK TYPE

0029

.772

(19,6)

.174

(4,19)

1.435

(36,44)

.548

(13,91)

= Detent Positions (90º )

= Key pull possible in these positions

= Stop Positions

LEGEND

8

GLOSS BLACK FACING

2

STAINLESS STEEL FACING

2

TWO NICKEL PLATED BRASS KEYS

C

4 TUMBLER SINGLE BITTED LOCK WITH DETENT

LOCK FINISH

Key part number: 119091029

NOTE: All orders keyed alike with code number on key. For more than one key code,

replacement keys, or other special features, consult Customer Service Center.

90º

Position 1

Positions 1& 2

ON

OFF

YM0613

YM061U

SP

SCHEMATIC

INDEXING

LOCK

CONFIGURATION

KEY PULL

POSITIONS

SWITCH FUNCTION

POS. 1

POS. 2

MODEL

NO.

NO.

POLES

2

POS. 1

POS. 1

2

SPST

Part number shown: YM0613C205NQ

All models

with all options when ordered with ‘Q’ contact material.
