Section 9 I/O Ports

Rev.1.00 Jun. 07, 2006 Page 484 of 1102

REJ09B0294-0100

9.3.2

Port Function Control Register 1 (PFCR1)

PFCR1 selects the

CS output pins.

Bit

Bit Name

Initial Value

R/W

CS7SA

R/W

CS7SB

R/W

CS6SA

R/W

CS6SB

R/W

CS5SA

R/W

CS5SB

R/W

CS4SA

R/W

CS4SB

R/W

Bit

Bit Name

Initial

Value

R/W

Description

CS7SA*

CS7SB*

R/W

CS7 Output Pin Select

Selects the output pin for

CS7 when CS7 output is

enabled (CS7E = 1)

00: Specifies pin PB3 as

CS7-A output

01: Specifies pin PB1 as

CS7-B output

10: Setting prohibited

11: Setting prohibited

CS6SA*

CS6SB*

R/W

CS6 Output Pin Select

Selects the output pin for

CS6 when CS6 output is

enabled (CS6E = 1)

00: Specifies pin PB2 as

CS6-A output

01: Specifies pin PB1 as

CS6-B output

10: Setting prohibited

11: Specifies pin PB6 as

CS6-D output

CS5SA*

CS5SB*

R/W

CS5 Output Pin Select

Selects the output pin for

CS5 when CS5 output is

enabled (CS5E = 1)

00: Specifies pin PB1 as

CS5-A output

01: Specifies pin PB0 as

CS5-B output

10: Setting prohibited

11: Specifies pin PB5 as

CS5-D output
