Section 9 I/O Ports

Rev.1.00 Jun. 07, 2006 Page 487 of 1102

REJ09B0294-0100

9.3.4

Port Function Control Register 4 (PFCR4)

PFCR4 enables/disables the address output.

Bit

Bit Name

Initial Value

R/W

A23E

R/W

A22E

R/W

A21E

R/W

A20E

0/1*

R/W

A19E

0/1*

R/W

A18E

0/1*

R/W

A17E

0/1*

R/W

A16E

0/1*

R/W

Bit

Bit Name

Initial

Value

R/W

Description

A23E

R/W

Address A23 Enable

Enables/disables the address output (A23)

0: Disables the A23 output

1: Enables the A23 output

A22E

R/W

Address A22 Enable

Enables/disables the address output (A22)

0: Disables the A22 output

1: Enables the A22 output

A21E

R/W

Address A21 Enable

Enables/disables the address output (A21)

0: Disables the A21 output

1: Enables the A21 output

A20E

0/1*

R/W

Address A20 Enable

Enables/disables the address output (A20)

0: Disables the A20 output

1: Enables the A20 output

A19E

0/1*

R/W

Address A19 Enable

Enables/disables the address output (A19)

0: Disables the A19 output

1: Enables the A19 output
