©2002-2016

DS20005022C

04/16

17

1 Mbit / 2 Mbit / 4 Mbit Multi-Purpose Flash

SST39SF010A / SST39SF020A / SST39SF040

Data Sheet

Figure 11:WE# Controlled Chip-Erase Timing Diagram

Figure 12:Software ID Entry and Read

1147 F17.1

WE#

SW0

SW1

SW2

SW3

SW4

SW5

5555

2AAA

2AAA

5555

5555

55

10

55

AA

80

AA

5555

OE#

CE#

SIX-BYTE CODE FOR CHIP-ERASE

Note: This device also supports CE# controlled Sector-Erase operation. The WE# and CE# signals are interchangeable

as long as minimum timings are met. (See Table 10)

Toggled bit output is always high first.

1147 F09.2

WE#

SW0

SW1

SW2

5555

2AAA

5555

0000

0001

OE#

CE#

Three-byte Sequence for

Software ID Entry

BF

Device ID

55

AA

90

Note: Device ID = B5H for SST39SF010A, B6H for SST39SF020A, and B7H for SST39SF040
