18 / 29 page

DS20005022C

04/16

1 Mbit / 2 Mbit / 4 Mbit Multi-Purpose Flash

SST39SF010A / SST39SF020A / SST39SF040

Data Sheet

Figure 13:Software ID Exit and Reset

Figure 14:AC Input/Output Reference Waveforms

Figure 15:A Test Load Example

1147 F10.0

ADDRESS A14-0

DQ7-0

TIDA

TWP

TWHP

WE#

SW0

SW1

SW2

5555

2AAA

5555

THREE-BYTE SEQUENCE FOR

SOFTWARE ID EXIT AND RESET

OE#

CE#

1147 F11.1

REFERENCE POINTS

OUTPUT

INPUT

VIT

VIHT

VILT

VOT

AC test inputs are driven at VIHT (3.0V) for a logic “1” and VILT (0V) for a logic “0”. Measure-

ment reference points for inputs and outputs are VIT (1.5V) and VOT (1.5V). Input rise

Note: VIT - VINPUT Test

VOT - VOUTPUT Test

VIHT - VINPUT HIGH Test

VILT - VINPUT LOW Test

1147 F12.0

TO TESTER

TO DUT

RL LOW

RL HIGH

VDD
