ASIX ELECTRONICS CORPORATION
9
AX88658AB 8-Port 10/100/1000BASE-T Ethernet Switch
CONFIDENTIAL
COL1
I/PD
V12
Collision Detect: Please references section 2.1.1.
CRS1
I/PD
U12
Carrier Sense: Please references section 2.1.1.
RX_DV1
I
W11
Receive Data Valid: Please references section 2.1.1.
RX_CLK1
I
V11
Receive Clock Input: Please references section 2.1.1.
RXD1[7:0]
I/PD Y11, U10, V10
W10, Y10
U9, V9, W9
Receive Data: Please references section 2.1.1.
2.1.3 RGMII/GMII/MII Interface Port 2
Signal Name
I/O
Pin No.
Description
GTX_CLK2
O
Y15
125MHz Clock Output: Please references section 2.1.1.
TX_EN2
O
U14
Transmit Enable: Please references section 2.1.1.
TXD2[7:0]
O
V14, W14,
Y14, V13,
W13,Y13,
W12, Y12
Transmit Data: Please references section 2.1.1.
TX_CLK2
I/PD
W18
MII Transmit Clock Input: Please references section 2.1.1.
COL2
I/PD
Y19
Collision Detect: Please references section 2.1.1.
CRS2
I/PD
W19
Carrier Sense: Please references section 2.1.1.
RX_DV2
I
V17
Receive Data Valid: Please references section 2.1.1.
RX_CLK2
I
Y18
Receive Clock Input: Please references section 2.1.1.
RXD2[7:0]
I/PD
W17, Y17,
U16, V16,
W16, Y16,
V15, W15
Receive Data: Please references section 2.1.1.
2.1.4 RGMII/GMII/MII Interface Port 3
Signal Name
I/O
Pin No.
Description
GTX_CLK3
O
T20
125MHz Clock Output: Please references section 2.1.1.
TX_EN3
O
U17
Transmit Enable: Please references section 2.1.1.
TXD3[7:0]
O
U18, U19,
U20, V18,
V19, V20,
W20, Y20
Transmit Data: Please references section 2.1.1.
TX_CLK3
I/PD
P17
MII Transmit Clock Input: Please references section 2.1.1.
COL3
I/PD
N20
Collision Detect: Please references section 2.1.1.
CRS3
I/PD
N19
Carrier Sense: Please references section 2.1.1.
RX_DV3
I
P19
Receive Data Valid: Please references section 2.1.1.
RX_CLK3
I
P18
Receive Clock Input: Please references section 2.1.1.
RXD3[7:0]
I/PD P20, R17, R18,
R19, R20, T17,
T18, T19
Receive Data: Please references section 2.1.1.
