7 / 140 page  Data Sheet ADP1055 Rev. A | Page 7 of 140 Parameter Symbol Test Conditions/Comments Min Typ Max Unit Temperature Coefficient VDD = 3.3 V 30 mV Range 0 mV to 19 mV 326 ppm/°C 0 mV to 21 mV 354 ppm/°C 60 mV Range 0 mV to 41 mV 172 ppm/°C 0 mV to 45 mV 194 ppm/°C 480 mV Range 0 mV to 374 mV 83 ppm/°C 0 mV to 414 mV 84 ppm/°C CURRENT SENSE MEASUREMENT ACCURACY (CS2+, CS2− PINS) 30 mV Setting 0 mV to 19 mV −2.9 +2.9 % FSR 0 mV to 21 mV −3.1 +3.1 % FSR 60 mV Setting 0 mV to 41 mV −1.9 +1.9 % FSR 0 mV to 45 mV −2.1 +2.1 % FSR 480 mV Setting 0 mV to 374 mV −1.5 +1.5 % FSR 0 mV to 414 mV −1.7 +1.7 % FSR Internal Level Shifting Current All ranges 25 μA CS2 Accurate OCP Speed 2.6 ms COMMON-MODE VOLTAGE OFFSET ERROR (CS2+, CS2− PINS) Maximum voltage differential from CS2− to AGND of ±50 mV 30 mV Range −1.0 +1.0 % FSR 60 mV Range −0.5 +0.5 % FSR 480 mV Range −0.25 +0.25 % FSR CS2 OCP FAST COMPARATORS (CS2+, CS2− PINS) For CS2 fast OCP and peak constant current mode CS2 Forward Comparator Accuracy Range of 0 mV to 60 mV Threshold set at 0 mV −10.3 % FSR Threshold set at 15.24 mV −10.1 % FSR Threshold set at 30.48 mV −23.8 +16.7 % FSR Threshold set at 45.71 mV −10.2 % FSR Threshold set at 60 mV −10.2 % FSR Range of 0 mV to 600 mV Threshold set at 0 mV −0.8 % FSR Threshold set at 152.4 mV 0.1 % FSR Threshold set at 304.8 mV −7.1 +7.6 % FSR Threshold set at 457.1 mV 0.9 % FSR Threshold set at 600 mV 1.3 % FSR Reverse Comparator Accuracy Range of 0 mV to 30 mV Threshold set at 0 mV −11.8 % FSR Threshold set at 7.62 mV −11.8 % FSR Threshold set at 15.24 mV −13.8 +16.9 % FSR Threshold set at 22.86 mV 12.7 % FSR Threshold set at 30 mV 12.5 % FSR Range of −30 mV to 0 mV Threshold set at 0 mV 17.1 % FSR Threshold set at −7.62 mV 16.9 % FSR Threshold set at −15.24 mV −9.5 +23.2 % FSR Threshold set at −22.86 mV 17.6 % FSR Threshold set at −30 mV 17.4 % FSR Propagation Delay Register 0xFE2D[1:0] = 00 (diode emulation mode) 40 80 ns JTD TEMPERATURE SENSE ADC Clock Frequency 1.56 MHz Update Rate For updating registers (14-bit resolution) Reverse Sensing Enabled 200 ms Reverse Sensing Disabled 130 ms |
|
