POE-D10-00-E-13
SAFETY STANDARDS REGULATED, REINFORCED
INSULATION TYPE, AH SERIES
Ver: 13
Page: 8 / 18
5. Marking:
1.Type Designation
AH
2.Nominal Capacitance
3-digit-system
3.Capacitance Tolerance
C:±0.25pF,D:±0.5pF,J:±5%,K:±10%,M:±20%
4.Company Name Code(Trade mark)
5. Products ID
Abbreviation ex.:
6.Approved Monogram:
(1) VDE approval mark
IEC 60384-14
Class Code：X1：400V~，Y1：250V~ or400V~
(2) UL approval mark
(6) DEMKO approval mark
(3) CSA approval mark
(7) FIMKO approval mark
(4) SEMKO approval mark
(8) SEV approval mark
(5) NEMKO approval mark
(9) CQC approval mark
Normal marking
YP*AH102K*****
(Special marking)
Two sides
（
（
（
（for SAP part number 10-11
digits ≤
≤
≤
≤“
“
“
“07
07
07
07 ”
”
”
”
products）
）
）
）
One side
（
（
（
（for SAP part number 10-11
digits ≥
≥
≥
≥“
“
“
“08
08
08
08”
”
”
”
products）
）
）
）
0AH
1AH
* Marking by the laser.
*“
“
“
“
C”：
：
：
：Marked with code “ _ ” stand for Halogen and Pb free epoxy resin.
