ADP1876
Data Sheet
Rev. A | Page 16 of 24
THERMAL OVERLOAD PROTECTION
The ADP1876 has an internal temperature sensor that senses
the junction temperature of the chip. When the junction tem-
perature of the ADP1876 reaches approximately 155°C, the
ADP1876 enters thermal shutdown, where the converter,
VCCO, and VOUTLDO are turned off and SSx discharges
toward zero through an internal 1 kΩ resistor. When the
junction temperature drops below 135°C, the ADP1876
resumes normal operation after the soft start sequence.
