Data Sheet

SSM4567

Rev. 0| Page 45 of 52

LIMITER CONTROL 2 REGISTER

Address: 0x0E, Reset: 0x73, Name: LIMITER_CTRL_2

Table 40. Bit Descriptions for LIMITER_CTRL_2

Bits

Bit Name

Settings

Description

Reset

Access

[7:6]

LIM_RRT

Limiter Release Rate

0x1

R/W

3200 ms/dB

1600 ms/dB

1200 ms/dB

800 ms/dB

[5:4]

LIM_ATR

Limiter Attack Rate

0x3

R/W

120 μs/dB

60 μs/dB

30 μs/dB

20 μs/dB

[3:0]

LIM_THRES

Limiter Attack Threshold

0x3

R/W

0000

6.6 V peak Output

0001

6.4 V peak Output

0010

6.2 V peak Output

0011

6.0 V peak Output

0100

5.8 V peak Output

0101

5.6 V peak Output

0110

5.4 V peak Output

0111

5.2 V peak Output

1000

5.0 V peak Output

1001

4.8 V peak Output

1010

4.6 V peak Output

1011

4.4 V peak Output

1100

4.2 V peak Output

1101

4.0 V peak Output

1110

3.8 V peak Output

1111

3.6 V peak Output
