SSM4567

Data Sheet

Rev. 0| Page 48 of 52

FAULT CONTROL REGISTER

Address: 0x12, Reset: 0x30, Name: FAULT_CTRL

Table 44. Bit Descriptions for FAULT_CTRL

Bits

Bit Name

Settings

Description

Reset

Access

[7:6]

OTW_GAIN

Over Thermal Warning Gain Reduction

0x0

R/W

No gain reduction in thermal warning

1.5 dB gain reduction in thermal warning

3 dB gain reduction in thermal warning

5.625 dB gain reduction in thermal warning

[5:4]

MAX_AR

Maximum Fault recovery Attempts. The Maximum autorecovery register determines

how many attempts at auto recovery are performed.

0x3

R/W

1 Autorecovery Attempt

3 Autorecovery Attempts

7 Autorecovery Attempts

Unlimited Autorecovery Attempts

MRCV

Manual Fault Recovery

0x0

Normal Operation

Writing of 1 causes a manual fault recovery attempt when

ARCV_OC/ARCV_OT/ARCV_UV/ARCV_BST = 1

ARCV_UV

Undervoltage Autofault Recovery Control

0x0

R/W

Auto Fault Recovery for Undervoltage Fault

Manual Fault Recovery for Undervoltage Fault

ARCV_OT

Overtemperature Auto Fault Recovery Control

0x0

R/W

Auto Fault Recovery for Overtemperature Fault

Manual Fault Recovery for Overtemperature Fault

ARCV_OC

Overcurrent Auto Fault Recovery Control

0x0

R/W

Auto Fault Recovery for Overcurrent Fault

Manual Fault Recovery for Overcurrent Fault
